mig weld brass welding wires

Free Sample Copper Alloy Zinc Brazing Tig Filler Rods MIG Weld Brass Welding Wires 1.6mm HS221 OEM Naidi Brand

Key attributes:

diameter: 1.6mm 2.4 3.0 4.0 5.0mm

flux content: none

material: brass welding wires

melting point: 890-905

customized support: OEM, ODM, OBM

weight: 5kg/pvc box ,20kg/carton

place of origin: Hebei, China

model number: ND-221 gb CU6810A

brand name: Naidi

application: for brass, copper gas welding as a filler material

Material: Copper / Copper Alloy

Product Name: Copper-Zinc Brazing rod Brass welding wires 1.6mm hs221

Type: ontent of tin and silicon special brass wire

PACKING: 5kg/pvc box ,20kg/carton

Trade Term: FOB CIF CFR EXW

Conductivity %lacs: 23-26

usage: brazing steel and cast iron and inlaid carbide cutting tools

Tensile strength mpa: 400

Color: Copper Bright

cu: 59-61.0

Packaging and delivery:

Selling Units: Single item

Single package size: 100X4X4 cm

Single gross weight: 20.000 kg

Product Description:

Copper-Zinc Brazing rod Brass welding wires 1.6mm hs221

ND-221 TIN BRASS WELDING WIRE

COMPLY  WITH GB AWS

CU6810A --

Description:Is the content of tin and silicon special brass wires. Tin can improve the flow of wire, and silicon can effectively control the evaporation of zinc to eliminate the pores, so as to get a good weld.

Uses: suitable for brass, copper gas welding as a filler material, but also widely used in brazing steel and cast iron and inlaid carbide cutting tools. Can also be used as low pressure valve sealing surface, light load wear surface surfacing materials.

Chemical composition of Welding wire%

cu: 59.0-61.0

sn: 0.5-1.0

si: 0.15-0.35

zn: bal.

Physical properties:

Proportion: 8.4 kg/dm3

Melting temperature:  890-905 ℃

Hot conductivity: 120 (w/m.k)

Conductivity: 23-26 %lacs

Mechanical properties of deposited metal (as reference):

Tensile strength mpa: 400

Elongation:  25%

hb: 100

Precautions:

1. must be taken to clean the groove and wire surface before welding

2. Welding before the general preheat to the temperature of 400-500 ℃ after welding. Welding must be used in conjunction with copper gas flux or gas flux.

3. Gas welding flame should be slightly oxidized flame, the appropriate reduction in welding temperature, improve the welding speed, to minimize the pool at high temperatures to reduce the time to reduce the evaporation and oxidation of zinc

1M ROD(TIG/GATW):

DIA(mm): 1.6 2.4 3.0 4.0 5.0

Welding current(a): 70-120 120-160 170-230 220-280 280-330

FAQ

Q: are your trading company or manufacturer?

A:we are factory

Q:how long is your delivery time:

A:Generally it's 7-15 days if the goods are in stock,or it's 15-20days if goods are not in stock,it depends on quantity.

Q:Do you provide free sample?it's free or extra?

A:yes,we offer free sample,but don't pay the cost of freight.

Q:what is your payment term?

A:payment<=1000usd,100% in="" advance.payment="">1000usd ,30%TT in advance,balance before shippment.

If you have another question, pls feel free to contact us as below:
